OEM#: CSSWDM3537New OEM Original Outright
MOTOR, .5HP, 3450RPM, 3PH, 60HZ, 56C, 3513M, TENV, F1 by BALDOR
Your price:
$1,985.30 each
OEM#: CSSWDM3537MOTOR, .5HP, 3450RPM, 3PH, 60HZ, 56C, 3513M, TENV, F1 by BALDOR
New OEM Original Outright
Your price:
$1,985.30 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, .5HP,3450RPM,3PH,60HZ,56C,3513M,TENV,F1
Features:
Food processing, packaging, outdoor and highly corrosive environments.
Features:
- All external surfaces 300 series stainless steel: motor frame, endplates, conduit box, shaft, and base
- Moisture resistant 200°C ISR® (Inverter Spike Resistant) magnet wire
- Four condensate drains in each endplate
- Enplate rabbets sealed and conduit box gasketed
- Lip seals
- Especially effective in highly corrosive environments where paint or other finishes do not hold up.
Food processing, packaging, outdoor and highly corrosive environments.
Technical Specs
P/N: CSSWDM3537 Key Specs
Item
MOTOR, .5HP, 3450RPM, 3PH, 60HZ, 56C, 3513M, TENV, F1
OEM
BALDOR
OEM #
CSSWDM3537
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
CSSWDM3537
Bearing-Opp-Drive-End
6203
C-Dimension Inches
11.09
Country of Origin
USA
Drive End Flange
C-Face
Enclosure
TENV
Enclosure Type
Totally Enclosed
Fl Amps
1.9-1.8/.9
Frame
56C
Hertz
60
Horsepower
1/2
Is_Motor
Yes
Motor Rpm 60Hz
3450
Mounting
Rigid
Phase
3
Poles
2
Rpm
3450
Rpm Range
3001-3600
Service Factor
1.15
Voltage
208-230/460
Weight
34
Baldor-Reliance Motor, .5HP,3450RPM,3PH,60HZ,56C,3513M,TENV,F1
Features:
Food processing, packaging, outdoor and highly corrosive environments.
Features:
- All external surfaces 300 series stainless steel: motor frame, endplates, conduit box, shaft, and base
- Moisture resistant 200°C ISR® (Inverter Spike Resistant) magnet wire
- Four condensate drains in each endplate
- Enplate rabbets sealed and conduit box gasketed
- Lip seals
- Especially effective in highly corrosive environments where paint or other finishes do not hold up.
Food processing, packaging, outdoor and highly corrosive environments.
