OEM#: CSWDM3542New OEM Original Outright
MOTOR, .75HP, 1750RPM, 3PH, 60HZ, 56C, 3514M, TENV, F1 by BALDOR
Your price:
$1,302.53 each
OEM#: CSWDM3542MOTOR, .75HP, 1750RPM, 3PH, 60HZ, 56C, 3514M, TENV, F1 by BALDOR
New OEM Original Outright
Your price:
$1,302.53 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, .75HP,1750RPM,3PH,60HZ,56C,3514M,TENV,F1
Features:
Food processing, packaging and outdoor applications. Severe environments where motors are washed on a regular basis.
Features:
- Moisture resistant ISR® (Inverter Spike Resistant) 200°C magnet wire
- Sealed ball bearings with moisture resistant grease
- Contact lip seals on shaft extensions
- Neoprene gaskets
- Special processed cast endplates
- 300 Series stainless steel motor frame, base, shaft and hardware
- No exterior paint
- Tropicalized
Food processing, packaging and outdoor applications. Severe environments where motors are washed on a regular basis.
Technical Specs
P/N: CSWDM3542 Key Specs
Item
MOTOR, .75HP, 1750RPM, 3PH, 60HZ, 56C, 3514M, TENV, F1
OEM
BALDOR
OEM #
CSWDM3542
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
CSWDM3542
Bearing-Opp-Drive-End
6203
C-Dimension Inches
11.06
Country of Origin
USA
Drive End Flange
C-Face
Enclosure
TENV
Enclosure Type
Totally Enclosed
Fl Amps
2.8/1.4
Frame
56C
Hertz
60
Horsepower
3/4
Is_Motor
Yes
Motor Rpm 60Hz
1750
Mounting
Rigid
Phase
3
Poles
4
Rpm
1750
Rpm Range
1701-1800
Service Factor
1.25
Voltage
230/460
Weight
31
