OEM#: FDL3712TMNew OEM Original Outright

MOTOR, 10HP, 1725RPM, 1PH, 60HZ, 215T, 3750LC, TEFC, F by BALDOR

Your price:
$3,262.47 eachReady to ship
HomeBALDORFDL3712TM
MOTOR, 10HP, 1725RPM, 1PH, 60HZ, 215T, 3750LC, TEFC, F by BALDOR
MOTOR, 10HP, 1725RPM, 1PH, 60HZ, 215T, 3750LC, TEFC, F by BALDOR

OEM#: FDL3712TM
MOTOR, 10HP, 1725RPM, 1PH, 60HZ, 215T, 3750LC, TEFC, F by BALDOR

New OEM Original Outright
Your price:
$3,262.47 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 10HP,1725RPM,1PH,60HZ,215T,3750LC,TEFC,F

Features:
  • Ball bearings, lubricated with high temperature moisture-resistant grease
  • Condensation drains
  • Gasketed cast conduit boxed
  • Farm duty epoxy paint for protection from harsh environments
  • 1.00 Service Factor
Typical Applications:
Wide variety of agri-duty and industrial applications.

Technical Specs
P/N: FDL3712TM Key Specs
Item
MOTOR, 10HP, 1725RPM, 1PH, 60HZ, 215T, 3750LC, TEFC, F
OEM
BALDOR
OEM #
FDL3712TM
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6307
C-Dimension Inches
20.77
Country of Origin
USA
Design Code
L
Drive End Flange
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
40
Fl Efficiency
84
Frame
215T
Hertz
60
Horsepower
10
Insulation Class
F
Is_Motor
Yes
Kva-Code
G
Motor Rpm 60Hz
1725
Mounting
Rigid
Opposite End Bearing Size
6206
Phase
1
Poles
4
Power-Factor
94
Rpm
1725
Rpm Range
1701-1800
Service Factor
1
Spec. Number
37M344T040
Voltage
230
Weight
160
Baldor-Reliance Motor, 10HP,1725RPM,1PH,60HZ,215T,3750LC,TEFC,F

Features:
  • Ball bearings, lubricated with high temperature moisture-resistant grease
  • Condensation drains
  • Gasketed cast conduit boxed
  • Farm duty epoxy paint for protection from harsh environments
  • 1.00 Service Factor
Typical Applications:
Wide variety of agri-duty and industrial applications.
