OEM#: WDM3542New OEM Original Outright

MOTOR, .75HP, 1750RPM, 3PH, 60HZ, 56, 3514M, TENV, F1 by BALDOR

Your price:
$982.95 eachReady to ship
HomeBALDORWDM3542
MOTOR, .75HP, 1750RPM, 3PH, 60HZ, 56, 3514M, TENV, F1 by BALDOR
MOTOR, .75HP, 1750RPM, 3PH, 60HZ, 56, 3514M, TENV, F1 by BALDOR

OEM#: WDM3542
MOTOR, .75HP, 1750RPM, 3PH, 60HZ, 56, 3514M, TENV, F1 by BALDOR

New OEM Original Outright
Your price:
$982.95 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, .75HP,1750RPM,3PH,60HZ,56,3514M,TENV,F1

Features:
  • Moisture sealant on bolt heads, between frame and endplates
  • Neoprene gaskets
  • Double sealed bearings
  • Forsheda® running contact v-ring slinger
  • Stainless steel shaft
  • Electrostatically applied epoxy finish
  • Class F insulation
  • Tropicalized
Typical Applications:
Food processing and other applications where motor is regularly exposed to high pressure wash down.

Technical Specs
P/N: WDM3542 Key Specs
Item
MOTOR, .75HP, 1750RPM, 3PH, 60HZ, 56, 3514M, TENV, F1
OEM
BALDOR
OEM #
WDM3542
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
WDM3542
Bearing-Opp-Drive-End
6203
C-Dimension Inches
11.06
Country of Origin
USA
Drive End Flange
Standard
Enclosure
TENV
Enclosure Type
Totally Enclosed
Fl Amps
2.8/1.4
Frame
56
Hertz
60
Horsepower
3/4
Is_Motor
Yes
Motor Rpm 60Hz
1750
Mounting
Rigid
Phase
3
Poles
4
Rpm
1750
Rpm Range
1701-1800
Service Factor
1.25
Voltage
230/460
Weight
32
Baldor-Reliance Motor, .75HP,1750RPM,3PH,60HZ,56,3514M,TENV,F1

Features:
  • Moisture sealant on bolt heads, between frame and endplates
  • Neoprene gaskets
  • Double sealed bearings
  • Forsheda® running contact v-ring slinger
  • Stainless steel shaft
  • Electrostatically applied epoxy finish
  • Class F insulation
  • Tropicalized
Typical Applications:
Food processing and other applications where motor is regularly exposed to high pressure wash down.
