OEM#: OJUI-01-08New OEM Original Outright
DRYLIN R OPEN LINEAR POLYMER BEARING WITH SHELL - 1/2"DIA. SHAFT by igus
Your price:
$26.07 each
OEM#: OJUI-01-08DRYLIN R OPEN LINEAR POLYMER BEARING WITH SHELL - 1/2"DIA. SHAFT by igus
New OEM Original Outright
Your price:
$26.07 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
DryLin R Open Linear Polymer Bearing with Shell - 1/2"Dia. Shaft
Special Features:
Special Features:
- Anodized aluminum adapter
- Dimensions interchangeable with linear ball bearings
- Equipped with liner made from iglide® J: temperature range -40°F to +194°F. JUI-01 (standard)
- T500 liner optional for chemicals/high temps (up to 482°F for steel housing, 356°F for aluminum)
- Suitable shafting for iglide® J: DryLin® AWI aluminum, case-hardened, 300 series stainless. Best shafting for T500: hard-chrome and hard-stainless steel
Technical Specs
P/N: OJUI-01-08 Key Specs
Item
DRYLIN R OPEN LINEAR POLYMER BEARING WITH SHELL - 1/2"DIA. SHAFT
OEM
igus
OEM #
OJUI-01-08
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Diagram Dimension D2
1.5625
Diagram Dimension Dn
0.82
Diagram Dimension Do
0.6846
Diagram Dimension Ds
0.8556
Diagram Dimension S
0.052
Dimension B
1.2461
Dimension B1
0.987
Dimension F
0.136
Dimension G
0.625
Dimension W
0.394
Dynamic Load Lbs. @ 0°
226
Dynamic Load Lbs. @ 180°
80
Dynamic Load Lbs. @ 90°
154
Manufacturer Name
igus, Inc.
Nominal Size Inches
1-1/2
Static Load Lbs. @ 0°
1575
Static Load Lbs. @ 180°
555
Static Load Lbs. @ 90°
1078
Temperature (°F)
-40 to 194
Tolerance
0.0016-0.0032
DryLin R Open Linear Polymer Bearing with Shell - 1/2"Dia. Shaft
Special Features:
Special Features:
- Anodized aluminum adapter
- Dimensions interchangeable with linear ball bearings
- Equipped with liner made from iglide® J: temperature range -40°F to +194°F. JUI-01 (standard)
- T500 liner optional for chemicals/high temps (up to 482°F for steel housing, 356°F for aluminum)
- Suitable shafting for iglide® J: DryLin® AWI aluminum, case-hardened, 300 series stainless. Best shafting for T500: hard-chrome and hard-stainless steel
Product Overview
DryLin R Open Linear Polymer Bearing with Shell - 1/2"Dia. Shaft
Special Features:
Special Features:
- Anodized aluminum adapter
- Dimensions interchangeable with linear ball bearings
- Equipped with liner made from iglide® J: temperature range -40°F to +194°F. JUI-01 (standard)
- T500 liner optional for chemicals/high temps (up to 482°F for steel housing, 356°F for aluminum)
- Suitable shafting for iglide® J: DryLin® AWI aluminum, case-hardened, 300 series stainless. Best shafting for T500: hard-chrome and hard-stainless steel
Technical Specs
P/N: OJUI-01-08 Key Specs
Item
DRYLIN R OPEN LINEAR POLYMER BEARING WITH SHELL - 1/2"DIA. SHAFT
OEM
igus
OEM #
OJUI-01-08
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Diagram Dimension D2
1.5625
Diagram Dimension Dn
0.82
Diagram Dimension Do
0.6846
Diagram Dimension Ds
0.8556
Diagram Dimension S
0.052
Dimension B
1.2461
Dimension B1
0.987
Dimension F
0.136
Dimension G
0.625
Dimension W
0.394
Dynamic Load Lbs. @ 0°
226
Dynamic Load Lbs. @ 180°
80
Dynamic Load Lbs. @ 90°
154
Manufacturer Name
igus, Inc.
Nominal Size Inches
1-1/2
Static Load Lbs. @ 0°
1575
Static Load Lbs. @ 180°
555
Static Load Lbs. @ 90°
1078
Temperature (°F)
-40 to 194
Tolerance
0.0016-0.0032
DryLin R Open Linear Polymer Bearing with Shell - 1/2"Dia. Shaft
Special Features:
Special Features:
- Anodized aluminum adapter
- Dimensions interchangeable with linear ball bearings
- Equipped with liner made from iglide® J: temperature range -40°F to +194°F. JUI-01 (standard)
- T500 liner optional for chemicals/high temps (up to 482°F for steel housing, 356°F for aluminum)
- Suitable shafting for iglide® J: DryLin® AWI aluminum, case-hardened, 300 series stainless. Best shafting for T500: hard-chrome and hard-stainless steel
Product Overview
DryLin R Open Linear Polymer Bearing with Shell - 1/2"Dia. Shaft
Special Features:
Special Features:
- Anodized aluminum adapter
- Dimensions interchangeable with linear ball bearings
- Equipped with liner made from iglide® J: temperature range -40°F to +194°F. JUI-01 (standard)
- T500 liner optional for chemicals/high temps (up to 482°F for steel housing, 356°F for aluminum)
- Suitable shafting for iglide® J: DryLin® AWI aluminum, case-hardened, 300 series stainless. Best shafting for T500: hard-chrome and hard-stainless steel
Technical Specs
P/N: OJUI-01-08 Key Specs
Item
DRYLIN R OPEN LINEAR POLYMER BEARING WITH SHELL - 1/2"DIA. SHAFT
OEM
igus
OEM #
OJUI-01-08
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Diagram Dimension D2
1.5625
Diagram Dimension Dn
0.82
Diagram Dimension Do
0.6846
Diagram Dimension Ds
0.8556
Diagram Dimension S
0.052
Dimension B
1.2461
Dimension B1
0.987
Dimension F
0.136
Dimension G
0.625
Dimension W
0.394
Dynamic Load Lbs. @ 0°
226
Dynamic Load Lbs. @ 180°
80
Dynamic Load Lbs. @ 90°
154
Manufacturer Name
igus, Inc.
Nominal Size Inches
1-1/2
Static Load Lbs. @ 0°
1575
Static Load Lbs. @ 180°
555
Static Load Lbs. @ 90°
1078
Temperature (°F)
-40 to 194
Tolerance
0.0016-0.0032
DryLin R Open Linear Polymer Bearing with Shell - 1/2"Dia. Shaft
Special Features:
Special Features:
- Anodized aluminum adapter
- Dimensions interchangeable with linear ball bearings
- Equipped with liner made from iglide® J: temperature range -40°F to +194°F. JUI-01 (standard)
- T500 liner optional for chemicals/high temps (up to 482°F for steel housing, 356°F for aluminum)
- Suitable shafting for iglide® J: DryLin® AWI aluminum, case-hardened, 300 series stainless. Best shafting for T500: hard-chrome and hard-stainless steel
