OEM#: PRT-01-150New OEM Original Outright
250MM DIA. SLEWING RING BEARING - 17,984 LBS MAX AXIAL STATIC by igus
Your price:
$842.00 each
OEM#: PRT-01-150250MM DIA. SLEWING RING BEARING - 17,984 LBS MAX AXIAL STATIC by igus
New OEM Original Outright
Your price:
$842.00 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
250mm Dia. Slewing Ring Bearing - 17,984 lbs Max Axial Static
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
Technical Specs
P/N: PRT-01-150 Key Specs
Item
250MM DIA. SLEWING RING BEARING - 17,984 LBS MAX AXIAL STATIC
OEM
igus
OEM #
PRT-01-150
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Color
Metal/Yellow
Dimension A
20
Dimension B
5.5
Dimension D
250mm
Dimension D1
165
Dimension D2
220
Dimension H
12
Dimension R1
110
Dimension R2
96.5
Dimension S1
M5
Dimension S2
5.5
Dimension T1
12 x 30°
Dimension T2
16 x 22.5°
K1 Screw (Din912)
DIN 912 M5
Manufacturer
igus, Inc.
Max Axial Dynamic
5,620 lbs.
Max Axial Static
17,984 lbs.
Max Radial Dynamic
1,798 lbs.
Max Radial Static
5,620 lbs.
250mm Dia. Slewing Ring Bearing - 17,984 lbs Max Axial Static
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
