OEM#: CRH28VBUURNew OEM Original Outright
CAM FOLLOWER-INCH HD FULL COMP CROWNED OD HEX HOLE DBL SEALED 1-3/4" OD 1"W 1-14 UNS THR by IKO International
Your price:
$69.68 each
OEM#: CRH28VBUURCAM FOLLOWER-INCH HD FULL COMP CROWNED OD HEX HOLE DBL SEALED 1-3/4" OD 1"W 1-14 UNS THR by IKO International
New OEM Original Outright
Your price:
$69.68 each
Asset Information
Must purchase minimum of 2
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Cam Follower-INCH, Heavy Duty, Full Complement, Crowned OD, Hex Hole, Double Sealed, 1-3/4" OD, 1" Width, 1-14 UNS Thread
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
Technical Specs
P/N: CRH28VBUUR Key Specs
Item
CAM FOLLOWER-INCH HD FULL COMP CROWNED OD HEX HOLE DBL SEALED 1-3/4" OD 1"W 1-14 UNS THR
OEM
IKO International
OEM #
CRH28VBUUR
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Style
Crowned OD
Clamping Diameter (F) Minimum Mm (Inch)
32.941 (1-19/64)
Country of Origin
Japan
Crown Radius (R) Mm (Inch)
500 (20)
Dimension B
27.4mm (1.08")
Dimension B2
44.450mm (1-3/4")
Dimension B3
11.112mm (7/16")
Dimension C1
1.588mm (1/16")
Dimension G1
4.762mm (3/16")
Dimension G2
2.381mm (3/32")
Dimension H
7.938mm (5/16")
Dynamic Load Rating (N)
35300
Needle Construction
Full Complement
O.D. Tolerance (Mm)
+0 / -0.50
Od (D) Mm/Inch
44.450 (1-3/4)
Oil Hole
Stud End, Stud Outside
Radial Clearance
0.010 to 0.030
Series
CR
Static Load Rating (N)
55600
Stud Diameter (D1) Mm (Inch)
25.400 (1)
Temperature Range F
-20°-120°F
Thread (G) Unf
1-14 UNS
Tolerance For Mounting Hole (Mm / Inch)
+0.041 / +0.020 (+.0016 / +.0008)
Tolerance For Stud Diameter (Mm)
+0.25 / -0
Torque Max (Nm)
258
Track Capacity (N)
4210
Type
Double Sealed
Width (C) Mm/Inch
25.400 (1)
Width (C) Tolerance (Mm)
+0 / -0.130
IKO Cam Follower-INCH, Heavy Duty, Full Complement, Crowned OD, Hex Hole, Double Sealed, 1-3/4" OD, 1" Width, 1-14 UNS Thread
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
Product Overview
IKO Cam Follower-INCH, Heavy Duty, Full Complement, Crowned OD, Hex Hole, Double Sealed, 1-3/4" OD, 1" Width, 1-14 UNS Thread
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
Technical Specs
P/N: CRH28VBUUR Key Specs
Item
CAM FOLLOWER-INCH HD FULL COMP CROWNED OD HEX HOLE DBL SEALED 1-3/4" OD 1"W 1-14 UNS THR
OEM
IKO International
OEM #
CRH28VBUUR
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Style
Crowned OD
Clamping Diameter (F) Minimum Mm (Inch)
32.941 (1-19/64)
Country of Origin
Japan
Crown Radius (R) Mm (Inch)
500 (20)
Dimension B
27.4mm (1.08")
Dimension B2
44.450mm (1-3/4")
Dimension B3
11.112mm (7/16")
Dimension C1
1.588mm (1/16")
Dimension G1
4.762mm (3/16")
Dimension G2
2.381mm (3/32")
Dimension H
7.938mm (5/16")
Dynamic Load Rating (N)
35300
Needle Construction
Full Complement
O.D. Tolerance (Mm)
+0 / -0.50
Od (D) Mm/Inch
44.450 (1-3/4)
Oil Hole
Stud End, Stud Outside
Radial Clearance
0.010 to 0.030
Series
CR
Static Load Rating (N)
55600
Stud Diameter (D1) Mm (Inch)
25.400 (1)
Temperature Range F
-20°-120°F
Thread (G) Unf
1-14 UNS
Tolerance For Mounting Hole (Mm / Inch)
+0.041 / +0.020 (+.0016 / +.0008)
Tolerance For Stud Diameter (Mm)
+0.25 / -0
Torque Max (Nm)
258
Track Capacity (N)
4210
Type
Double Sealed
Width (C) Mm/Inch
25.400 (1)
Width (C) Tolerance (Mm)
+0 / -0.130
IKO Cam Follower-INCH, Heavy Duty, Full Complement, Crowned OD, Hex Hole, Double Sealed, 1-3/4" OD, 1" Width, 1-14 UNS Thread
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
Product Overview
IKO Cam Follower-INCH, Heavy Duty, Full Complement, Crowned OD, Hex Hole, Double Sealed, 1-3/4" OD, 1" Width, 1-14 UNS Thread
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
Technical Specs
P/N: CRH28VBUUR Key Specs
Item
CAM FOLLOWER-INCH HD FULL COMP CROWNED OD HEX HOLE DBL SEALED 1-3/4" OD 1"W 1-14 UNS THR
OEM
IKO International
OEM #
CRH28VBUUR
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Style
Crowned OD
Clamping Diameter (F) Minimum Mm (Inch)
32.941 (1-19/64)
Country of Origin
Japan
Crown Radius (R) Mm (Inch)
500 (20)
Dimension B
27.4mm (1.08")
Dimension B2
44.450mm (1-3/4")
Dimension B3
11.112mm (7/16")
Dimension C1
1.588mm (1/16")
Dimension G1
4.762mm (3/16")
Dimension G2
2.381mm (3/32")
Dimension H
7.938mm (5/16")
Dynamic Load Rating (N)
35300
Needle Construction
Full Complement
O.D. Tolerance (Mm)
+0 / -0.50
Od (D) Mm/Inch
44.450 (1-3/4)
Oil Hole
Stud End, Stud Outside
Radial Clearance
0.010 to 0.030
Series
CR
Static Load Rating (N)
55600
Stud Diameter (D1) Mm (Inch)
25.400 (1)
Temperature Range F
-20°-120°F
Thread (G) Unf
1-14 UNS
Tolerance For Mounting Hole (Mm / Inch)
+0.041 / +0.020 (+.0016 / +.0008)
Tolerance For Stud Diameter (Mm)
+0.25 / -0
Torque Max (Nm)
258
Track Capacity (N)
4210
Type
Double Sealed
Width (C) Mm/Inch
25.400 (1)
Width (C) Tolerance (Mm)
+0 / -0.130
IKO Cam Follower-INCH, Heavy Duty, Full Complement, Crowned OD, Hex Hole, Double Sealed, 1-3/4" OD, 1" Width, 1-14 UNS Thread
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
IKO Cam Followers consist of needle rollers, stud acting inner ring raceway and thick-walled outer ring to withstand heavy rolling or shock loads. Cam Followers are available with cylindrical or crowned outer rings. The crowned outer ring alleviates uneven loads resulting from deflection, bending or misalignment in mounting. There are two internal designs available; one with a cage for high speed, and another with a full complement for heavy loads. Cam Followers are follower bearings for cam mechanisms or linear motions, and widely used for machine tools, industrial robots, electronic devices and office automation equipment utilizing their high rigidity and accuracy. These cam followers are provided with pre-packed grease. Sufficient lubrication is also needed between cam followers and steel track on which cam followers run, to prevent seizure and to reduce friction. An appropriate nut is supplied with the stud.
