OEM#: CRY52VUURNew OEM Original Outright
ROLLER FOLLOWER- FULL COMP- INCH, CROWNED OD, DOUBLE SEALED, 3-1/4" OD by IKO International
Your price:
$148.74 each
OEM#: CRY52VUURROLLER FOLLOWER- FULL COMP- INCH, CROWNED OD, DOUBLE SEALED, 3-1/4" OD by IKO International
New OEM Original Outright
Your price:
$148.74 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Roller Follower- Full Comp- Inch, CRY52VUUR, Crowned OD, Double Sealed, 3-1/4" OD
IKO Non-separable Yoke Type Roller Follower is full complement bearing with inner ring, side plates and thick-walled outer ring to withstand heavy rolling or shock loads. Its surface is treated with black oxide coating. Roller Followers are available with Crowned or Cylindrical outer rings. The crowned outer ring relieves edge load created by mounting error and the cylindrical is suitable for applications with large loads or low track surface hardness due to a large contact area with mating track surface. Sufficient lubrication is needed between roller followers and steel track on which cam followers run, to prevent seizure and to reduce friction.
IKO Non-separable Yoke Type Roller Follower is full complement bearing with inner ring, side plates and thick-walled outer ring to withstand heavy rolling or shock loads. Its surface is treated with black oxide coating. Roller Followers are available with Crowned or Cylindrical outer rings. The crowned outer ring relieves edge load created by mounting error and the cylindrical is suitable for applications with large loads or low track surface hardness due to a large contact area with mating track surface. Sufficient lubrication is needed between roller followers and steel track on which cam followers run, to prevent seizure and to reduce friction.
Technical Specs
P/N: CRY52VUUR Key Specs
Item
ROLLER FOLLOWER- FULL COMP- INCH, CROWNED OD, DOUBLE SEALED, 3-1/4" OD
OEM
IKO International
OEM #
CRY52VUUR
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Style
Crowned OD
Bore Diameter Millimeters (Inch)
25.400 (1)
Bore Tolerance (Mm)
+0.002 / -0.012
Country of Origin
Japan
Crown Radius (R) Mm (Inch)
760 (30)
Dynamic Load Rating (N)
77600
Needle Construction
Full Compliment
O.D. Tolerance (Mm)
+0 / -0.050
Od Mm (Inch)
82.550 (3-1/4)
Oil Hole & Groove
At inner ring
Outer Ring Width Mm (Inch)
44.450 (1-3/4)
Overall Width Mm (Inch)
46.038 (1.8125)
Prepacked Grease
YES
Radial Clearance
0.035 to 0.060
Retainer
None
Series
CRY
Shaft Dia Drive Fit (Mm)
25.397 to 25.410
Shaft Dia Press Fit (Mm)
25.408 to 25.420
Shaft Dia Push Fit (Mm)
25.377 to 25.390
Side Plate Od (A) Mm (Inch)
54.0 (2.125)
Static Load Rating (N)
172000
Tolerance Outer Ring Width (Mm)
+0 / -0.130
Tolerance Overall Width (Mm)
+0.130 / -0.250
Track Capacity (N)
12700
Type
Double Sealed
IKO Roller Follower- Full Comp- Inch, CRY52VUUR, Crowned OD, Double Sealed, 3-1/4" OD
