OEM#: LRB404828New OEM Original Outright
INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING INCH, 2-1/2" BORE, 3" OD, 44.7MM WIDTH by IKO International
Your price:
$56.12 each
OEM#: LRB404828INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING INCH, 2-1/2" BORE, 3" OD, 44.7MM WIDTH by IKO International
New OEM Original Outright
Your price:
$56.12 each
Asset Information
Must purchase minimum of 2
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Inner Ring for Machined Type Needle Roller Bearing INCH, 2-1/2" Bore, 3" OD, 44.7mm Width
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings
Technical Specs
P/N: LRB404828 Key Specs
Item
INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING INCH, 2-1/2" BORE, 3" OD, 44.7MM WIDTH
OEM
IKO International
OEM #
LRB404828
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Appropriate Outer Ring
BR486028, BR486028UU
Bore (D) Mm/Inch
63.500 (2-1/2)
Bore Tolerance (Mm)
+0 / -0.015
Country of Origin
Japan
O.D. Tolerance (Mm)
-0.028 / -0.046
Od (F) Mm/Inch
76.200 (3)
Oil Hole
Yes
Series
LRB
Shaft Fillet Corner Radius Max (Mm)
2
Shaft Shoulder (Da) Max (Mm)
73
Shaft Shoulder (Da) Min (Mm)
71
Width (B) Mm
44.7
Width Tolerance (Mm)
+0 / -0.130
IKO Inner Ring for Machined Type Needle Roller Bearing INCH, 2-1/2" Bore, 3" OD, 44.7mm Width
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings
